Solution Ultima 844/862/880 Installation Manual
AUX Indicator
If Option 8 in “LOCATION 444” on page 241 has been enabled, the AUX indicator will be used to
display when the control panel is using the telephone line. The
AUX indicator will also flash in unison
with the
PARTIAL indicator when Installer’s Programming Mode or Master Code Functions are used.
Indicator Definition
On
System Is Armed In STAY Mode 1 Or STAY Mode 2
Off
System Is Not Armed In STAY Mode
Flashing
Zone Isolating Mode Or Setting STAY Mode 2 Zones
Table 151: AUX Indicator
MAINS Indicator
The MAINS indicator is used to display that the systems AC mains supply is normal or has failed.
When programming numbers (i.e. Installer’s Programming Mode or Master Code Functions), the
MAINS indicator will illuminate when you program numbers between 10 and 15. The MAINS
indicator represents digit 10 plus the value of the illuminated zone indicator (e.g.: If you program a
twelve, the
MAINS indicator and zone 2 will illuminate).
Indicator Definition
On
AC Mains Power Normal
Flashing
AC Mains Failure
Table 152: MAINS Indicator
FAULT Indicator
The FAULT indicator is used to display that the system has detected a system fault. Refer to Fault
Analysis Mode on page 95 for more information on system faults.
Every time a new system fault has been detected (e.g.: FAULT indicator flashing), the codepad will
begin to beep once every minute.
Pressing the
button once will cancel the once a minute beep and acknowledge the fault (e.g.:
FAULT indicator on).
Indicator Definition
On
There Is A System Fault That Needs To Be Rectified
Off
The System Is Normal, There Are No Faults
Flashing
There Is A System Fault Waiting To Be Acknowledged
Table 153: FAULT Indicator
