Solution Ultima 844/862/880 Installation Manual
Command 963 - Copy From Programming Key To Control Panel
This command is used to copy data from the programming key to the control panel. Only the
Programming Key (CC891) may be used with the
Solution Ultima 844/862/880 control
panel.
How To Copy The Programming Key Memory To The Control Panel
1. Enter Installer's Programming Mode (i.e.. 1234followed by the #button).
Two beeps will be heard and the
STAY and AWAY indicators will begin to flash on the remote
codepad to indicate that you have entered Installer’s Programming Mode. You will also notice
that the remote codepad will display the data currently programmed in “LOCATION 000”.
2. Connect the programming key onto the pins marked PROGRAMMING KEY on the control
panel found at the top of the PCB (printed circuit board) next to the Auxiliary Module socket.
3. Enter command
963followed by the #button.
Two beeps will be heard after the programming key's data has successfully been copied into to
the control panel. If you heard a long beep after issuing this command, the programming key
has become corrupt and will need to be erased to clear the corrupt data. Refer to Command
964 - Erase Programming Key on page 113 for more information.
4. Before removing the programming key from the control panel, enter command
960
followed by the
# button to exit Installer's Programming Mode. The STAY and AWAY
indicators will now extinguish on the remote codepad and the system will return to the
disarmed state.
Failing to exit Installer’s Programming Mode before removing the programming key may
result in corrupting the programming key.
How To Copy Programming Key Memory To Control Panel Using Hand Held Programmer
1. Before connecting the hand held programmer onto the pins marked PROGRAMMING KEY,
make sure that the switch on the hand held programmer is in the EXT position and that no
external key has been plugged onto the hand held programmer.
2. Enter Installer's Programming Mode (i.e..
1234followed by the #button).
Two beeps will be heard and the hand held programmer will display the data currently
programmed in “LOCATION 000”.
3. Plug the programming key onto the pins marked EXTERNAL KEY on the hand held
programmer.
4. Enter command 963followed by the #button.
Two beeps will be heard after the programming key's data has successfully been copied into to
the control panel. If you heard a long beep after issuing this command, the programming key
has become corrupt and will need to be erased to clear the corrupt data. Refer to Command
964 - Erase Programming Key on page 113 for more information.
5. Before removing the programming key from the hand held programmer, enter command
960followed by the #button to exit Installer's Programming Mode. Two beeps will be
heard and the system will now return to the disarmed state.
Failing to exit Installer’s Programming Mode before removing the programming key may
result in corrupting the programming key.
ISSUE162.DOC Electronics Design and Manufacturing Pty Limited
