200 Solution Ultima 844/862/880 Installation Manual
Outputs
The Solution Ultima 844/862/880 control panel has four fully programmable outputs on the
main PCB and one other programmable output that operates the codepad buzzer. These four outputs
are factory default to operate a horn speaker, fire alarm verification, strobe and an internal screamer.
Outputs 1 – 4 will NOT operate whilst the control panel detects a low battery.
Programmable outputs require four parameters to be programmed in order to operate correctly.
Event Type: When To Operate
Polarity: How To Operate
Time Base: How Long To Operate For
Time Multiplier: How Often To Operate
Event Polarity Time Time
Type Base Multiplier
When To Operate Is selected from the output event types listed on page 202. Each digit
should be entered into the two corresponding locations for the output
event type required.
How To Operate Is selected from "Table 117: Event Type Polarities” on page 211. This
determines whether the output remains operating for the duration of
the event, pulses for the duration, operates once only (one shot) or
latches on.
How Long To Operate For Is determined by a time base and a multiplier. Refer to "Timing Of
Outputs" on page 213 for further information.
How Often To Operate For Is determined by a time base and a multiplier. Refer to "Timing Of
Outputs" on page 213 for further information.
Output Defaults
Location 380 - 385
Output 1
Default For Horn
Speaker
Location 398 – 403
Relay
Default For
Sirens Running
Location 386 - 391 Location 392 - 397
Default For Default For Strobe
Fire Alarm Verification (Reset In 8 Hrs)
Location 404 – 409
Default For Entry/Exit
Warning + Day Alarm
1 14 0 0 0 0
Output 2
27 10 215
Strobe
2 0 6 4 0 8
1 15 1 0 0 0
Codepad
0132 1 0 1
Event Type Polarity Time Base Time Multiplier
