System Reporting Information 185
Zone Status – Bypass Reports
LOCATION 329 - 330 98
Location Description
329
Zone Bypass Report
330
Zone Bypass Restore Report
Table 90: Zone Status - Bypass Report Locations
A zone is bypassed when it is manually isolated. Refer to Isolating Zones on page 48 for information
on isolating zones. A "Zone Bypass" report (Contact ID Event Code 573) will be sent at the end of
exit time for any zone that has been manually isolated. 24-hour zones will send a “Zone Bypass”
report at the time the zone has been selected to be isolated.
A "Zone Bypass Restore" report will be sent when the system has been disarmed. All bypassed zones
are automatically cleared when the system has been disarmed.
The bypass code parameter is used as the expansion digit in 4+2 Formats. It has no effect on Contact
ID Format as a zone bypass will always be reported on event code 570.
If "Zone Bypass" reports are not required, program "LOCATION 329 - 330" with a zero.
Contact ID Event Code 572 will report when any 24-Hour burglary zones have been manually
bypassed. Contact ID Event Code 571 will report when any 24-Hour fire zones have been
manually Isolated.
Zone Status – Trouble Reports
LOCATION 331 – 332 23
Location Description
331
Zone Trouble Report
332
Zone Trouble Restore Report
Table 91: Zone Status - Trouble Report Locations
A zone is in trouble when it is unsealed at the end of exit time. A "Sensor Trouble" report (Contact ID
Event Code 380) will be sent to indicate that one or more zones have been automatically isolated by
the system. 24-hour zones that are unsealed at the end of exit time will not send a "Sensor Trouble"
report as the restore for that zone is still outstanding.
A "Sensor Trouble" restore report will be sent for burglary zones when the zone reseals or when the
system is next disarmed (which ever happens first). A 24-hour zone will only send a restore signal
when it has resealed.
The trouble code parameter is used as the expansion digit in 4+2 Format. It has no effect on Contact
ID Format as a "Sensor Trouble" report will always be reported on event code 380.
If "Sensor Trouble" reports are not required, program "LOCATION 331 – 332" with a zero.
Electronics Design and Manufacturing Pty Limited ISSUE162.DOC
