Dialler Reporting Formats 131
Point ID Codes
The table below shows the different Point ID Codes and Event Codes that are sent to the base station
receiver when using Contact ID Reporting Format. All event codes are fixed and will always send the
same code as there are no programming locations made available to alter these.
Event
Code
Event
Description
Point ID
Number
Explanation Page
130 Burglary Zone
Zone Specific
1 - 8
Burglary Page 171
100 Medical Zone 24 Hour Medical Page 171
120 Panic Zone 24 Hour Panic Page 171
122 Hold-Up Zone 24 Hour Hold-Up Page 171
137 Tamper Zone 24 Hour Tamper Page 171
133 Burglary Zone 24 Hour Burglary Page 171
110 Fire 24 Hour Fire Page 171
401 Open/Close Report
User Specific
1 - 16
Opening – User #
Closing – User #
Page 189
402
Open/Close Report
Partitioned
User Specific
1 - 16
Opening – User #
Closing – User #
Page 189
456 Partial Close Report
User Specific
1 – 16
Closing – User # Page 154
301 AC Mains Fail
030
AC Power Page 193
309 Low Battery
031
Battery Test Failure Page 194
121 Codepad Duress
User Specific
1 - 16
Duress Alarm Page 190
120 Codepad Panic
041
Panic Alarm Page 190
110 Codepad Fire
046
Fire Alarm Page 191
100 Codepad Medical
045
Medical Alarm Page 191
421 Code Retry Limit Exceeded
042
Access Denied Page 195
602 Test Report - Automatic
044
Test Report Page 197
602 Test Report After Siren Reset
047
Test Report Page 231
307 Sensor Self Test Failure
Zone Specific
1 – 8
Sensor Watch Page 186
Zone Specific
1 - 8
RF Device Supervision Page 187
380 Trouble
Zone Specific
1 - 8
Sensor Trouble Page 185
300 Fuse Fail
00
System Trouble Page 192
Electronics Design and Manufacturing Pty Limited ISSUE162.DOC
