EDM Solution Ultima 844 - STAY Indicator; FAULT Indicator; MAINS Indicator

Codepad Indicators 29
STAY Indicator
The STAY indicator is used to display that the system is armed in STAY Mode 1 or STAY Mode 2.
The
STAY indicator will also flash in unison with the AWAY indicator when Installer’s Programming
Mode or Master Code Functions are used.
For the different methods of arming the system in STAY Mode 1, refer to page 42. Refer to Zone
Options 2 on page 179 for information on setting zones to be automatically isolated in STAY Mode 1.
For the method of arming the system in STAY Mode 2, refer to page 45. Refer to Setting STAY
Mode 2 Zones on page 71 when using the Installer Code or Setting STAY Mode 2 Zones on page 86
when using the Master Code.
Indicator Definition
On
System Is Armed In STAY Mode 1 Or STAY Mode 2
Off
System Is Not Armed In STAY Mode
Flashing
Zone Isolating Mode Or Setting STAY Mode 2 Zones
Once Every 3 Seconds
Day Alarm Status On/Off Indicator
Table 7: STAY Indicator
MAINS Indicator
The MAINS indicator is used to display that the systems AC mains supply is normal or has failed.
When programming numbers (i.e. Installer’s Programming Mode or Master Code Functions), the
MAINS indicator will illuminate when you program numbers between 10 and 15. The MAINS
indicator represents digit 10 plus the value of the illuminated zone indicator (e.g.: If you program a
twelve, the
MAINS indicator and zone 2 will illuminate).
Indicator Definition
On
AC Mains Power Normal
Flashing
AC Mains Failure
Table 8: MAINS Indicator
FAULT Indicator
The FAULT indicator is used to display that the system has detected a fault. Refer to Fault
Descriptions on page 53 for more information on system faults.
Every time a new system fault has been detected (e.g.: FAULT indicator flashing), the codepad will
begin to beep once every minute.
Pressing the
button once will cancel the once a minute beep and acknowledge the fault (e.g.:
FAULT indicator on).
Indicator Definition
On
There Is A System Fault That Needs To Be Rectified
Off
The System Is Normal, There Are No Faults
Flashing
There Is A System Fault Waiting To Be Acknowledged
Table 9: FAULT Indicator
