194 Solution Ultima 844/862/880 Installation Manual
System Status - Low Battery Report
LOCATION 364 - 365 1
Location Description
364
System Status – Low Battery Reporting Code (Tens Digit)
365
System Status – Low Battery Reporting Code (Units Digit)
Table 110: System Status – Low Battery Report Locations
A "Battery Test Failure" report (Contact ID Event Code 309) will be sent to the base station receiver
when the systems battery voltage falls below 10.5 volts or when a dynamic battery test detects a low
capacity battery.
A dynamic battery test is performed every time the system has been armed as well as every four hours
from power up of the control panel. Refer to Fault Descriptions on page 53 for more information.
If a "Low Battery" report is not required, program "LOCATION 364 - 365" with a zero.
Outputs 1 – 4 will NOT operate whilst the control panel detects a low battery.
System Status - Low Battery Restore Report
LOCATION 366 - 367
Location Description
366
System Status – Low Battery Restore Report (Tens Digit)
367
System Status – Low Battery Restore Report (Units Digit)
Table 111: System Status – Low Battery Restore Report Locations
A "Low Battery” restore report will be sent if the back up battery has been restored the next time the
system has been armed, or when the next dynamic battery test reports the battery test is OK.
If a "Low Battery Restore" report is not required, program "LOCATION 366 - 367" with a zero.
ISSUE162.DOC Electronics Design and Manufacturing Pty Limited
