Operating Codepads In Partitioning
Operating From A CP5 Area Addressable LED Codepad
When operating a CP5 Area Addressable (CP500A) codepad in a system that has been partitioned, the
display and operations are exactly the same as the CP5 Eight Zone LED codepad except that the
commands issued from the codepad only effects the area that the codepad is allocated to. Refer to
System Operations on page 40 for more information on operating the system.
Example
If the codepad is allocated to Area 2, only user codes that have been allocated to Area 2 can operate
the codepad. If user codes only have access to Area 1, entering their code at the Area 2 codepad will
not work.
If you wish to determine which codepad you are currently operating, hold down the 8 button to
determine which area that the codepad is allocated to (i.e.. If Zone 1 illuminates, the codepad is
allocated to Area 1, if Zone 2 illuminates, the codepad is allocated to Area 2). Refer to Hold Down
Functions on page 93 for more information.
Operating From A CP5 Master Partitioned Codepad
When operating a CP5 Master Partitioned (CP500P) codepad in a system that has been partitioned, all
operations are the same as the CP5 Area Addressable codepad with one exception. All operations are
only related to the Area Display that is being indicated on the codepad at the time (i.e.. If the Area
Display illuminates number 2, the codepad is displaying information only for Area 2. Therefore, all
operations will only effect Area 2).
Refer to System Operations on page 40 for more information on operating the system.
How To Move From One Area To The Next
1. Press the button.
The Area Display indicator will m
ove to the next area display (i.e.. If the Area Display
illuminates number 1, pressing the button will toggle to display Area 2. Pressing the
button a second time will toggle the display back to Area 1).
