Programming 107
Programming Option Bits
When programming these locations, you will notice that there are four alternatives per location. You
may select one, two, three or all of these alternatives for each location, however, only one number is
required to be programmed. This number is calculated by adding the option bit numbers together.
Example
If at "LOCATION 177" you want options 1, 2 and 4, add the numbers together and the total is the
number to be programmed. In this example, the number to be programmed is 7 (i.e.. 1 + 2 + 4 = 7).
Option Description
1
Enabled = Allow Dialler Reporting Functions
Disabled = Disable All Dialler Reporting Functions
2
Enable Remote Arming Via The Telephone
4
Enable Answering Machine Bypass Only When Armed
8
Enabled = Use Bell 103 For FSK Format
Disabled = CCITT V21 Format
Table 47: Example - Programming Option Bits
Installer’s Programming Commands
There are ten different commands that can be used to perform various functions once the Installer's
Programming Mode has been entered. To issue the command required, enter the corresponding
numerical code followed by the
# button (e.g.: 965# would set the system for domestic dialling for
Receiver 1).
Command Description Page
958
Enable/Disable Zone Status Mode 108
959
Test Programming Key 109
960
Exit Installer’s Programming Mode 110
961
Reset Control Panel Back To Factory Default Settings 110
962
Copy The Control Panel Memory To The Programming Key 111
963
Copy The Programming Key Data To The Control Panel 112
964
Erase Programming Key 113
965
Set Up Domestic Dialling Format (Receiver 1) 114
966
Enable/Disable Automatic Stepping Of Locations During
Programming
115
999
This Command Displays The Control Panel’s Software Version
Number Or Control Panel Type
117
Table 48: Installer's Programming Commands
Electronics Design and Manufacturing Pty Limited ISSUE162.DOC
