Transmission Formats
When making use of the control panel's dialling and communication features, there are a number of
transmission formats available. Refer to "LOCATION 033" on page 141 to set the required
transmission format for Receiver 1 and “LOCATION 073” on page 144 to set the required
transmission formation for Receiver 2. The
Solution Ultima 844/862/880 control panel
comes factory default to report in the Contact ID Format.
Contact ID Format
This format can identify hundreds of protection zones by their unique code and provides a single digit
event qualifier and a three-digit event code that quickly identifies the condition being reported.
Subscriber
ID Number
Qualifier
Event
Code
Group
Number
Point ID
Number
SSSS Q XYZ GG CCC
Four Digit
Subscriber ID
Number
Event Qualifier, Which Gives
Specific Event Information.
1 = New Event Or Opening
3 = New Restore Or Closing
Event Code
(Made Up Of 3
Hex Digits)
Group Number
(Made Up Of 2
Hex Digits)
Point ID Number
(Made Up Of 3
Hex Digits)
Table 54: Contact ID Format Breakdown
In general, Contact ID reporting format is very simple as most of the Event Codes and Point ID Codes
have been predefined. The base station software usually only has the ability to identify a zone going
into alarm by its Point ID Code and usually pays little attention to the Event Code.
Refer to "Table 55: Point ID Codes" on page 132 for further information on the
Solution Ultima
844/862/880
Point ID Codes.
