Partitioning 245
User Code Allocations
“LOCATION 462 – 477” is used to assign each user code to an area or multiple areas when the
Solution Ultima 880 control panel has been partitioned. A number 0 – 3 is required to be entered
into each of these locations to assign each user code holder to the areas they are required to operate.
Multiple user codes can be allocated to the same areas.
Select the required areas that the user code holder is to operate and then add the options values
together from “Table 159: User Code Allocations” below (e.g.: If the user code is allocated to operate
both Area 1 and Area 2, program a 3 (i.e.. 1 + 2 = 3) into the required location relevant to their user
code allocation. If the user code is allocated only to Area 1, program their user code allocation as 1).
Option Allocated Areas
0
Not Allocated To An Area
1
Allocated To Area 1
2
Allocated To Area 2
3
Allocated To Area 1 + Area 2
Table 159: User Code Allocations
Location 462 Location 463 Location 464 Location 465
User Code 1 0 User Code 2 0 User Code 3 0 User Code 4 0
Location 466 Location 467 Location 468 Location 469
User Code 5 0 User Code 6 0 User Code 7 0 User Code 8 0
Location 470 Location 471 Location 472 Location 473
User Code 9 0 User Code 10 0 User Code 11 0 User Code 12 0
Location 474 Location 475 Location 476 Location 477
User Code 13 0 User Code 14 0 User Code 15 0 User Code 16 0
Electronics Design and Manufacturing Pty Limited ISSUE162.DOC
