Solution Ultima 844/862/880 Installation Manual
Codepad Reporting Options
LOCATION 355 1
Option Description
0
No Report Required
1
Receiver 1
2
Receiver 2
4
Receiver 1 and Receiver 2
8
Receiver 2 Only When Receiver 1 Fails
Table 105: Codepad Reporting Options Location
This location is factory default to report only to Receiver 1. You can select whether the codepad
reporting options will report on Receiver 1, Receiver 2, both Receiver 1 and Receiver 2, Receiver 2
only when Receiver 1 fails or no reporting at all.
System Status – Fuse Fail Report
LOCATION 356 - 357
Location Description
356
System Status – Fuse Fail Reporting Code (Tens Digit)
357
System Status – Fuse Fail Reporting Code (Units Digit)
Table 106: System Status – Fuse Fail Report Locations
A system trouble report (Contact ID Event Code 300) will be sent when either the codepad fuse or the
accessories fuse has blown. A delay of approximately 10 seconds will be between from when the fuse
has blown and when the system will report the event.
System Status – Fuse Fail Restore Report
LOCATION 358 - 359
Location Description
358
System Status – Fuse Fail Restore Reporting Code (Tens Digit)
359
System Status – Fuse Fail Restore Reporting Code (Units Digit)
Table 107: System Status – Fuse Fail Restore Report Locations
A system trouble restore report (Contact ID Event Code 300) will be sent when either the codepad
fuse or the accessories fuse has been replaced. A delay of approximately 10 seconds will be between
from when the fuse has been replaced and when the system will report the event.
