Solution Ultima 844/862/880 Installation Manual
Programming Option Bits
When programming these locations, you will notice that there are four options per location. You may
select one, two, three or all four of these options, however, only one number needs to be programmed.
This number is calculated by adding the option bit numbers together. Program a seven (7) if you
require options 1, 2 and 4 simultaneously (i.e.. 1 + 2 + 4 = 7).
Example
If at "LOCATION 436" you want options 1, 2 and 4, add the numbers together and the total is the
number to be programmed. In this example, the number to be programmed is 7 (i.e.. 1 + 2 + 4 = 7).
Option Description
1
EDM Smart Lockout Allowed
2
Horn Speaker Monitor
4
Strobe Indications For Radio Arm/Disarm
8
Assign Button 4 On Transmitter To Operate STAY Mode 1
Table 137: Example - Programming Option Bits
ISSUE162.DOC Electronics Design and Manufacturing Pty Limited
