Zone Information 177
Keyswitch Zone Options
When you select a zone to be a keyswitch input, then the following table relates to the options
available to that keyswitch zone. These keyswitch zone options replace Zone Options 1 only for the
zones that have been programmed to operate as a keyswitch zone. Keyswitch zones will report as user
code 16.
Option Description
0
Latching Arm and Disarm In AWAY Mode
1
Latching Arm In AWAY Mode
2
Latching Disarm From AWAY Mode, STAY Mode 1 Or STAY Mode 2
4
Latching Arm and Disarm In STAY Mode 1
5
Latching Arm In STAY Mode 1
8
Momentary Arm and Disarm In AWAY Mode
9
Momentary Arm In AWAY Mode
10
Momentary Disarm From AWAY Mode, STAY Mode 1 Or STAY Mode 2
12
Momentary Arm and Disarm In STAY Mode 1
13
Momentary Arm In STAY Mode 1
0
1
2
4
5
6
Table 83: Keyswitch Zone Options
Latching Arm and Disarm In AWAY Mode
If this option has been selected, the system will either arm or disarm from AWAY Mode when using
the latching keyswitch input.
Latching Arm In AWAY Mode
If this option has been selected, the system will arm in AWAY Mode when using the latching
keyswitch input. Disarming the system will not be permitted via the keyswitch zone if this option has
been selected.
Latching Disarm From AWAY Mode, STAY Mode 1 Or STAY Mode 2
If this option has been selected, the system will disarm from AWAY Mode, STAY Mode 1 or STAY
Mode 2 when using the latching keyswitch input. Arming the system will not be permitted via the
keyswitch zone if this option has been selected.
Latching Arm and Disarm In STAY Mode 1
If this option has been selected, the system will arm or disarm in STAY Mode 1 when using the
latching keyswitch input. Arming and disarming the system in AWAY Mode will not be permitted
via the keyswitch zone if this option has been selected.
Latching Arm In STAY Mode 1
If this option has been selected, the system will arm in STAY Mode 1 when using the latching
keyswitch input. Arming the system in AWAY Mode or disarming the system will not be permitted
via the keyswitch zone if this option has been selected.
Latching Disarm From STAY Mode 1 Or STAY Mode 2
If this option has been selected, the system will only disarm from STAY Mode 1 or STAY Mode 2
when using the latching keyswitch input. Arming the system in STAY Mode 1, STAY Mode 2 or
arming and disarming the system in AWAY Mode will not be permitted via the keyswitch zone if this
option has been selected.
