Solution Ultima 844/862/880 Installation Manual
Command 958 - Enable/Disable Zone Status Mode
This function enables and disables the zone status display mode when using the hand held
programmer. The hand held programmer will display the zones on the seven-segment display from
left to right. If there is a dash illuminated on the display of the hand held programmer, the
corresponding zone is unsealed and if the display is blank, the zone is sealed.
The third (or centre) display shows either the number 4 or the number 8. The number 4 constantly
illuminated indicates that zones 1 - 4 are being displayed. The number 8 constantly illuminated
indicates that zones 5 - 8 are being displayed.
Pressing the
# button will toggle the display between the zones. This feature will prove to be very
useful during installation as the hand held programmer allows you to view the status of the zones
directly at the control panel, saving you time and money.
How To Enable Zone Status Mode
1. Enter Installers Programming Mode (i.e.. 1234followed by the #button).
Two beeps will be heard and the hand held programmer will display the data currently
programmed in “LOCATION 000”.
2. Enter command
958followed by the #button.
Two beeps will be heard and the number 4 will illuminate to indicate zones 1 – 4 are being
displayed.
How To Disable Zone Status Mode
1. Enter command 958followed by the #button.
Two beeps will be heard and you will return to the Installer’s Programming Mode.
Example
A " - " in the display indicates the zone is unsealed.
A blank display indicates the zone is sealed.
¤-4--indicates that zone 1 is sealed and zones 2, 3 and 4 are unsealed.
¤
¤-indicates that zones 5 and 8 are unsealed and zones 6 and 7 are sealed.¤8
¤
ISSUE162.DOC Electronics Design and Manufacturing Pty Limited
