174 Solution Ultima 844/862/880 Installation Manual
Zone Pulse Count Time
Zone pulse count time is the time frame or period over which the programmed number of pulses must
register before an alarm condition is generated.
20 ms Loop Response Time 150 ms Loop Response Time
Option Pulse Count Time Option Pulse Count Time
0
0.5 Seconds
8
20 Seconds
1
1 Second
9
30 Seconds
2
2 Seconds
10
40 Seconds
3
3 Seconds
11
50 Seconds
4
4 Seconds
12
60 Seconds
5
5 Seconds
13
90 Seconds
6
10 Seconds
14
120 Seconds
7
15 Seconds
15
200 Seconds
Table 81: Zone Pulse Count Times
For zone pulse count time, options 0 – 7 have a zone loop response time of 20 ms. For zone pulse
count time, options 8 – 15 have a zone loop response time of 150 ms. Loop response time is the
length of time a zone must be unsealed before it can register as a valid pulse.
Inertia sensors should use options 0 - 7, while PIR detectors should use options 8 – 15.
24-Hour zones do not receive any handover pulses from other zones. 24-Hour zones may
handover pulses to other zones.
ISSUE162.DOC Electronics Design and Manufacturing Pty Limited
