186 Solution Ultima 844/862/880 Installation Manual
Zone Status – Sensor Watch Reports
LOCATION 333 - 334 45
Location Description
333
Sensor Watch Report
334
Sensor Watch Restore Report
Table 92: Zone Status – Sensor Watch Report Locations
A "Self Test Failure" report (Contact ID Event Code 307) will be sent to the base station receiver
when a zone has not been triggered during the Sensor Watch Time programmed in "LOCATION 420
- 421" on page 218. This report will continue to be sent (according to the frequency of the sensor
watch time) until the fault has been rectified.
To clear the fault and stop any further reporting, the zone that registered the fault must be unsealed
and resealed again. Refer to "LOCATION 420 - 421" on page 218 to set the number of days a zone
may remain sealed before registering as a fault. Refer to Zone Options 1 on page 175 to program
zones to be monitored by the sensor watch feature.
If "Self Test Failure" reports are not required, program "LOCATION 333 - 334" with a zero.
Zone Status – Alarm Restore Code
LOCATION 335
If you wish the control panel to send zone alarm restore reports, this location should be programmed
as 14. If you do not wish to send zone restore reports, this location should be programmed as a zero.
“LOCATION 336” will be ignored when programming the alarm restore code and is global for all
zones. A zone restore report will only report to the receiving party that the zone has been allocated to
(e.g.: Receiver 1 or Receiver 2 etc).
Zone Status Reporting Options
LOCATION 336
Option Description
0
No Report Required
1
Receiver 1
2
Receiver 2
4
Receiver 1 and Receiver 2
8
Receiver 2 Only When Receiver 1 Fails
Table 93: Zone Status Reporting Options Location
This location is factory default to report only to Receiver 1. You can select whether the zone status
reports will report on, Receiver 1, Receiver 2, both Receiver 1 and Receiver 2, Receiver 2 only when
Receiver 1 fails or no reporting at all.
When using partitioned
Solution Ultima 880 control panels, this location will be ignored if
Option 1 – Lock Area 1 to Receiver 1 & Lock Area 2 to Receiver 2 in “LOCATION 445” on page
242 has been programmed.
ISSUE162.DOC Electronics Design and Manufacturing Pty Limited
