202 Solution Ultima 844/862/880 Installation Manual
Output Event Types
There are approximately seventy-five different output event types to choose from. Two numbers
designate each output event type. These two numbers need to be programmed into the appropriate
locations of the output being used to indicate when the output should operate.
All reset times are in reference to polarity 1 and 8. Reset times will vary depending on the
polarity used.
00 EDMSAT - Satellite Siren (Output 1 Only)
This output controls all functions of an EDMSAT satellite siren (SS914). The option of
speaker indication beeps will not operate via the EDMSAT for remote operations. No
polarity is required to be programmed for this output event type.
01 System Armed
This output will operate when the system is armed in AWAY Mode, STAY Mode 1 or
STAY Mode 2. The output will reset when the system has been disarmed. If the system
has been partitioned, this event will operate when both areas have been armed in AWAY
Mode or STAY Mode 1.
02 System Disarmed
This output will operate when the system is in the disarmed state. The output will reset as
soon as the system becomes armed. If the system has been partitioned, this event will
operate when both areas have been disarmed.
03 Armed In STAY Mode
This output will operate when the system has been armed in STAY Mode 1 or STAY Mode
2. The output will reset when the system is disarmed. If the system has been partitioned,
this event will operate when either area has been armed in STAY Mode 1.
04 Armed In AWAY Mode
This output will operate when the system has been armed in AWAY Mode. The output
will reset when the system is disarmed. If the system has been partitioned, this event will
operate when either area has been armed in AWAY Mode.
05 Auto Arm Pre-Arming Alert Time
This output will operate during the time period before the control panel will automatically
arm in AWAY Mode or STAY Mode 1. Once the control panel has automatically armed in
AWAY Mode or STAY Mode 1, the output will reset. To program the pre-arming alert
time, refer to “LOCATION 425” on page 220.
06 Exit Warning With All Zones Sealed Or Entry Warning
This output will operate during exit time when the control panel has been armed in AWAY
Mode, STAY Mode 1 or STAY Mode 2 if all zones are sealed. This output event type will
reset once exit time has expired.
The next time this output event type will operate will be during entry time and will reset
once entry time has expired or the system has been disarmed. This output event type will
also operate if a zone has triggered when the system has been armed in STAY Mode 1 or
STAY Mode 2 only if the Entry Guard Timer For STAY Mode has been programmed in
"LOCATION 416 - 417" on page 217.
ISSUE162.DOC Electronics Design and Manufacturing Pty Limited
