Dialler Information 149
Telephone Line Fault Options
LOCATION 176 0
When programming this location, you will notice that there are four options per location. If you
require options 1, 2, 4 or all of these options, only one number needs to be programmed. This number
is calculated by adding the option bit numbers together. Program a 7 if you require options 1, 2 and 4
simultaneously (i.e.. 1 + 2 + 4 = 7).
Option Description
1
Display FAULT Indicator When Telephone Line Fails
2
Sound Alarm When System Is Armed
4
Sound Alarm When System Is Disarmed
8
Reserved
Table 68: Telephone Line Fault Options
The
Solution Ultima 844/862/880 has the ability to monitor the telephone line. If the
telephone line has been cut or disconnected for more than forty seconds, the control panel will
recognise this and the
FAULT indicator will illuminate on the codepad. The FAULT indicator will
extinguish once the telephone line has been restored for more than forty seconds.
Option 2 and 4 will not operate unless option 1 has been enabled.
1
2
4
8
Operate The FAULT Indicator When Telephone Line Fails
The FAULT indicator will flash and the codepad buzzer will beep once every minute if the control
panel detects that the telephone line has been disconnected. Refer to Fault Descriptions on page 53
for more information.
Sound Speaker, Bell and Strobe When The System Is Armed
Option 1 in this location will also need to be selected for this option to operate. If the control panel
detects that the telephone line has been disconnected when the system is armed in AWAY Mode,
STAY Mode 1 or STAY Mode 2, the horn speaker, bell and strobe outputs will operate. Refer to
Option 2 in LOCATION 179 on page 155 to program Lockout Telephone Line Fail Alarm when only
one audible alarm per arming cycle is required.
Sound Speaker, Bell and Strobe When The System Is Disarmed
Option 1 in this location will also need to be selected for this option to operate. If the control panel
detects that the telephone line has been disconnected when the system is disarmed, the horn speaker,
bell and strobe outputs will operate. Refer to Option 2 in LOCATION 179 on page 155 to program
Lockout Telephone Line Fail Alarm when only one audible alarm per arming cycle is required.
Reserved
If Options 1, 2 and 4 have been added together, the horn speaker, bell, strobe and EDMSAT
outputs will operate when the system is armed or disarmed.
