36 Solution Ultima 844/862/880 Installation Manual
3
Area Display Indicators
A group of four Area Display indicators display which area is currently being displayed (i.e. If
number 1 is being displayed, all information provided on the codepad display relates only to Area 1.
If number 2 is being displayed, all information provided on the codepad display relates only to Area
2).
Pressing the button will toggle or move you to the next area display (i.e. If Area 1 is currently
being displayed, pressing the button will toggle or move you to Area 2. Pressing the
button a second time will toggle you back to display information for Area 1).
Area Display Indicators Definition
On
Indicates Current Area Being Displayed
Off
Indicates Current Area Not Being Displayed
Table 19: Area Display Indicators
Status Indicators
A group of four indicators display the following:
PARTIAL Indicator
The PARTIAL indicator is used to display that the system is armed in STAY Mode 1. The PARTIAL
indicator will also flash in unison with the
AUX indicator when Installer’s Programming Mode or
Master Code Functions are used.
For the different methods of arming the system in STAY Mode 1, refer to page 42. Refer to Zone
Options 1 on page 169 for information on setting zones to be automatically isolated in STAY Mode 1.
4
Indicator Definition
On
System Is Armed In STAY Mode 1
Off
System Is Not Armed In STAY Mode 1
Table 20: Partial Indicator
AUX Indicator
If Option 8 in “LOCATION 444” on page 241 has been enabled, the AUX indicator will be used to
display when the control panel is using the telephone line. The
AUX indicator will also flash in unison
with the
PARTIAL indicator when Installer’s Programming Mode or Master Code Functions are used.
Indicator Definition
On
System Is Armed In STAY Mode 1 Or STAY Mode 2
Off
System Is Not Armed In STAY Mode
Flashing
Zone Isolating Mode Or Setting STAY Mode 2 Zones
Table 21: AUX Indicator
ISSUE162.DOC Electronics Design and Manufacturing Pty Limited
