Programming 117
Command 999 - Display Panel Type Or Software Version Number
When using this command via the remote codepad, the codepad will display the panel version of the
control panel. As there are three different control panel’s using the same PCB, it is difficult to know
which control panel the PCB has been set up to be.
The codepad will display a 4, 6 or 8 depending on the software of the control panel. Refer to the
“Table 50: Control Panel Type” below for more information.
Indicator Control Panel Type
4
Solution Ultima 844
6
Solution Ultima 862
8
Solution Ultima 880
Table 50: Control Panel Type
When using this command via the hand held programmer, the hand held programmer will display the
software version number of the control panel.
How To Display The Control Panel Type Or Software Version Number
1. Enter Installer’s Programming Mode (i.e.. 1234followed by the #button).
Two beeps will be heard and the data currently programmed in “LOCATION 000” will be
displayed via the hand held programmer or remote codepad.
If you are using the remote codepad, the
STAY and AWAY indicators will begin to flash to
indicate that you have entered Installer’s Programming Mode.
2. Enter command
999followed by the #button.
Two beeps will be heard.
If you are using the hand held programmer, the right display will indicate the software version
number of the control panel.
If you are using the remote codepad, the codepad will display a zone indicator corresponding
to the control panel type. Refer to “Table 50: Control Panel Type” above for more
information.
3. Press the
#button to exit this command and return to the Installer’s Programming Mode.
4. Enter command
960 followed by the # button to exit Installer's Programming Mode.
Two beeps will be heard and the system will now return to the disarmed state.
If you are using the remote codepad, the
STAY and AWAY indicators will extinguish to indicate
that you have returned to the disarmed state.
Electronics Design and Manufacturing Pty Limited ISSUE162.DOC
