138 Solution Ultima 844/862/880 Installation Manual
Dialler Information
This section outlines the programming information required for the Solution Ultima
844/862/880
control panel when communicating with base station receivers. Typically these
parameters specify the telephone numbers to call, the transmission formats, handshake tones and
transmission speeds.
The
Solution Ultima 844/862/880 has the ability to report event information from two on-
board diallers. The first dialler reports to Receiver 1 and the second dialler reports to Receiver 2.
Each dialler has the ability to be programmed with two separate telephone numbers, handshake tone,
reporting format type and Subscriber ID Number.
Example
Dialler 1 could be set up to report in Domestic Dialling Format and reports to Receiver 1. Dialler 2
could be set up to report to a base station receiver in Contact ID Format only when Dialler 1 was
unsuccessful.
How To Program A Telephone Number
When programming the telephone number, if a '0' is required, it must be programmed as a '10'. Each
location in the primary, secondary and call back telephone numbers hold one digit of the telephone
number.
To tell the dialler when the end of the telephone number has been reached, a '0' must be inserted at the
end of the telephone number. Therefore the dialling sequence will be terminated when a zero appears.
Example
To program the telephone number 9672 1055 as the Primary Telephone Number for Receiver 1, you
would program the following:
LOCATION 000 - 015
96721 5500000000.
Programming A Four Second Pause In The Telephone Number
To enter a four-second pause in the dialling sequence, you would need to program the value '13'. This
may be necessary when the dialler is communicating through an old (slower) telephone exchange or
where a PABX system is in place.
Example
To program the telephone number 02 pause 9672 1055 as the Primary Telephone Number for
Receiver 2, you would program the following:
LOCATION 040 - 055
2 96721 5500000.
Digit Required Number To Program Digit Required Number To Program
Terminator
0
8
8
1
1
9
9
2
2
0
10
3
3
*
11
4
4
#
12
5
5
Four Second Pause
13
6
6
Break
14
7
7
15
15
Table 60: Dialling Digits
ISSUE162.DOC Electronics Design and Manufacturing Pty Limited
