Partitioning 243
Zone Allocations
Each area can have up to eight zones allocated to it. The eight locations for each area represents
ZONE indicators one to eight on the remote area addressable codepad. Any of the zone inputs 1 – 8
can be mapped to any area to appear as any zone on the remote area addressable codepad (i.e.. Any
zone can be programmed to both Area 1 and Area 2 to become common zones).
Zones that have been programmed as common zones (e.g.: Allocated to both Area 1 and Area 2) will
report to the base station receiver on group zero (i.e. Area 1 = Group 1 and Area 2 = Group 2). Zones
that are allocated only to one area will report on the corresponding group number. Common zones
that are programmed other than 24 hour zone types will not activate an alarm until both areas have
been armed in either AWAY Mode or STAY Mode 1.
Zone Allocations For Area 1
LOCATION 446 - 453 00000000
Location Description
446
Area 1 – Zone 1 Indicator
447
Area 1 – Zone 2 Indicator
448
Area 1 – Zone 3 Indicator
449
Area 1 – Zone 4 Indicator
450
Area 1 – Zone 5 Indicator
451
Area 1 – Zone 6 Indicator
452
Area 1 – Zone 7 Indicator
453
Area 1 – Zone 8 Indicator
Table 157: Solution Ultima 880 – Zone Allocations For Area 1
Zone Allocations For Area 2
LOCATION 454 - 461 00000000
Location Description
454
Area 2 – Zone 1 Indicator
455
Area 2 – Zone 2 Indicator
456
Area 2 – Zone 3 Indicator
457
Area 2 – Zone 4 Indicator
458
Area 2 – Zone 5 Indicator
459
Area 2 – Zone 6 Indicator
460
Area 2 – Zone 7 Indicator
461
Area 2 – Zone 8 Indicator
Table 158: Solution Ultima 880 – Zone Allocations For Area 2
Electronics Design and Manufacturing Pty Limited ISSUE162.DOC
