Programming 103
Programming With The Remote Codepad
When programming the control panel via the remote codepad, the system must be in the disarmed
state with no alarm memory present.
To access the Installer’s Programming Mode, enter the four digit followed by the
button. The factory default Installer Code is 1234. Two beeps will be heard and both
the
AWAY and the STAY indicators will flash simultaneously to indicate that you have entered
Installer’s Programming Mode.
When entering Installer’s Programming Mode, you will be automatically positioned at “LOCATION
000”, the beginning of the Primary Telephone Number for Receiver 1.
Data
Value
Zone 1
Indicator
Zone 2
Indicator
Zone 3
Indicator
Zone 4
Indicator
Zone 5
Indicator
Zone 6
Indicator
Zone 7
Indicator
Zone 8
Indicator
MAINS
Indicator
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Table 46: Codepad Indicators When Programming
Example
To access Installer’s Programming Mode, enter the followed by the button.
Two beeps will be heard and both the
AWAY and the STAY indicators will flash simultaneously to
indicate that you have entered Installer’s Programming Mode. The codepad indicators will display the
current data stored in the first location (LOCATION 000).
To move to another programming location, enter the required followed by the
button. The data of the new location will now be displayed (e.g.. 34followed by the
button will automatically step you to the beginning of the Subscriber ID Number for Receiver 1).
To move to the next location, press the button. This will step you to the next location and the
data in that location will be displayed (e.g.. If you are currently positioned at “LOCATION 034”,
pressing the button will step you to “LOCATION 035”).
If you press the
button without previously entering a location number, the system will step back
one location (e.g.. If you are positioned at “LOCATION 035” and you press the button, you
will step back one location to LOCATION 034).
Electronics Design and Manufacturing Pty Limited ISSUE162.DOC
