Solution Ultima 844/862/880 Installation Manual
RF Receiver Trouble Report
LOCATION 340 - 341 79
Location Description
340
RF Receiver Trouble Report (Tens Digit)
341
RF Receiver Trouble Report (Units Digit)
Table 96: RF Receiver Trouble Report Locations
A “RF Receiver Trouble” report (Contact ID Event Code 355) will be sent to the base station receiver
when the RF receiver registers one of the following events:
RF Signal Jamming - Point ID Code 001
RF Receiver Tamper Switch - Point ID Code 002
RF Receiver Failure - Point ID Code 003.
RF Receiver Trouble Restore Report
LOCATION 342 - 343 7
Location Description
342
RF Receiver Trouble Report (Tens Digit)
343
RF Receiver Trouble Report (Units Digit)
Table 97: RF Receiver Trouble Report Locations
A “RF Receiver Trouble Restore” report will be sent to the base station receiver when the RF receiver
no longer registers RF Signal Jamming, RF Receiver Tamper Switch or RF Receiver Failure.
RF Dialler Options
LOCATION 344
Option Description
0
No Report Required
1
Receiver 1
2
Receiver 2
4
Receiver 1 and Receiver 2
8
Receiver 2 Only When Receiver 1 Fails
Table 98: Zone Status Reporting Options Location
This location is factory default to report only to Receiver 1. You can select whether the zone status
reports will report on, Receiver 1, Receiver 2, both Receiver 1 and Receiver 2, Receiver 2 only when
Receiver 1 fails or no reporting at all.
ISSUE162.DOC Electronics Design and Manufacturing Pty Limited
