System Reporting Information 197
Test Reporting Time
LOCATION 372 - 378 0000 71 0
Location Description
372
Actual Hour Of The Day (Tens Digit)
373
Actual Hour Of The Day (Units Digit)
374
Actual Minute Of The Day (Tens Digit)
375
Actual Minute Of The Day (Units Digit)
376
Test Report Code (Tens Digit)
377
Test Report Code (Units Digit)
378
Repeat Interval In Days
Table 114: Test Reporting Time Locations
A "Test" report (Contact ID Event Code 602) is a specific signal that is sent to the base station
receiver and is normally used to test the dialling and reporting functions of the control panel. Test
reports will not be sent if the Subscriber ID Number is 0000.
When programming test reports, the control panel needs to know the hour and minute of the day the
report is required, as well as how often to send the report. Test reports are reported on a daily basis
ranging from every day to every fifteen days. Refer to "Set The Number Of Days Until The First Test
Report" on page 65 to set the first test report if required.
If you do not require "Test" reports, program the repeat interval in "LOCATION 378" as zero.
V1.05+
Test reports can be sent every 30 minute by programming the test report time as 34:00.
Example
If you wish to send test reports once every seven days at 11:35 PM, you would program “LOCATION
372 - 378” as follows:
2335 71 7
Test Reporting Dialler Options
LOCATION 379
Option Description
0
No Report Required
1
Receiver 1
2
Receiver 2
4
Receiver 1 and Receiver 2
8
Receiver 2 Only When Receiver 1 Fails
Table 115: Test Reporting Options Location
This location is factory default to report only to Receiver 1. You can select whether the test reporting
options will report on Receiver 1, Receiver 2, both Receiver 1 and Receiver 2, Receiver 2 only when
Receiver 1 fails or no reporting at all.
Electronics Design and Manufacturing Pty Limited ISSUE162.DOC
