96 Solution Ultima 844/862/880 Installation Manual
Zone
Indicator
Fault
Description
Hold Down
Button
Zone
Indicator
Fault
Condition
1 System Fault
1
1
Low Battery
2
Date & Time
3
RF Receiver Jamming
RF Receiver Tamper Switch
RF Receiver Comms Failure
4
Horn Speaker
5
Telephone Line Fail
6
E2 Fault
7
Fuse Fail
2
RF Low Battery
2
1 - 8
Zones 1 - 8 RF Low Battery
3 Zone Tamper Alarm
3
1 - 8
Zones 1 - 8 Tamper Alarm
4 Sensor Watch Fault
4
1 - 8
Zones 1 – 8 Sensor Watch
Fail
5 RF Sensor Watch
5
1 – 8
Zones 1 - 8 RF Sensor Watch
Fail
6 Communication Fail
6
1
Receiver 1 Fail
2
Receiver 2 Fail
6
7
Table 45: Fault Indicators
Initiate A Modem Call
Holding the 6button down until two beeps are heard will force the control panel to dial the call back
telephone number programmed in "LOCATION 159 - 174" on page 147 in an attempt to connect to
the installers remote computer.
The remote computer will be required to be running the Alarm Link Software (CC816) and will need
to be set to “Waiting For An Incoming Call". If no call back telephone number has been programmed,
holding down the
6button will have no effect.
Reset Latching Outputs
Holding the 7 button down until two beeps are heard will reset any programmable output that has
been programmed to remain on once it has been activated.
The output will need to be programmed with a latching polarity. Refer to Output Polarity on page 211
for further information.
ISSUE162.DOC Electronics Design and Manufacturing Pty Limited
