32 Solution Ultima 844/862/880 Installation Manual
STAY Indicator
The
STAY indicator is used to display that the system is armed in STAY Mode 1 or STAY Mode 2.
The
STAY indicator will also flash in unison with the AWAY indicator when Installer’s Programming
Mode or Master Code Functions are used.
The
indicator will also illuminate when the system is armed in STAY Mode 1 or STAY Mode
2.
For the different methods of arming the system in STAY Mode 1, refer to page 42. Refer to Zone
Options 2 on page 179 for information on setting zones to be automatically isolated in STAY Mode 1.
For the method of arming the system in STAY Mode 2, refer to page 45. Refer to Setting STAY
Mode 2 Zones on page 71 when using the Installer Code or Setting STAY Mode 2 Zones on page 86
when using the Master Code.
Indicator Definition
On
System Is Armed In STAY Mode 1 Or STAY Mode 2
Off
System Is Not Armed In STAY Mode
Flashing
Zone Isolating Mode Or Setting STAY Mode 2 Zones
Once Every 3 Seconds
Day Alarm Status On/Off Indicator
Table 13: STAY Indicator
System Disarmed
This indicator will illuminate with the indicator when the system has been disarmed.
MAINS Indicator
The
MAINS indicator is used to display that the systems AC mains supply is normal or has failed.
When programming numbers (i.e. Installer’s Programming Mode or Master Code Functions), the
MAINS indicator will illuminate when you program numbers between 10 and 15. The MAINS
indicator represents digit 10 plus the value of the illuminated zone indicator (e.g.: If you program a
twelve, the
MAINS indicator and zone 2 will illuminate).
Indicator Definition
On
AC Mains Power Normal
Flashing
AC Mains Failure
Table 14: MAINS Indicator
ISSUE162.DOC Electronics Design and Manufacturing Pty Limited
