Partitioning 237
Area On/Off Indicators
2
The group of four Area On/Off indicators (1 – 4) show the status of each area (i.e.. If an indicator is
illuminated, that area is armed and if the indicator is not illuminated, that area is disarmed).
If an area is armed in STAY Mode 1, the corresponding Area On/Off indicator will be illuminated in
conjunction with the
PARTIAL indicator. If the area is armed in AWAY Mode, only the
corresponding Area On/Off Indicator will be illuminated.
Area On/Off Indicator Definition
On
Area Is Armed In AWAY Mode Or STAY Mode 1
Off
Area Is Disarmed
3
Table 148: Area On/Off Indicators
Area Display Indicators
A group of four Area Display Indicators indicate which area is currently being displayed (i.e.. If
number 1 is being displayed, all information provided on the display relates only to Area 1. If number
2 is being displayed, all information provided on the display relates only to Area 2).
Pressing the
button will toggle or move you to the next area display (i.e.. If Area 1 is currently
being displayed, pressing the button will toggle or move you to Area 2. Pressing the
button a second time will toggle you back to display information for Area 1).
Area Display Indicators Definition
On
Indicates Current Area Being Displayed
Off
Indicates Current Area Not Being Displayed
Table 149: Area Display Indicators
Status Indicators
4
A group of four indicators display the following:
PARTIAL Indicator
The PARTIAL indicator is used to display that the system is armed in STAY Mode 1. The PARTIAL
indicator will also flash in unison with the
AUX indicator when Installer’s Programming Mode or
Master Code Functions are used.
For the different methods of arming the system in STAY Mode 1, refer to page 42. Refer to Zone
Options 1 on page 175 for information on setting zones to be automatically isolated in STAY Mode 1.
Indicator Definition
On
System Is Armed In STAY Mode 1
Off
System Is Not Armed In STAY Mode 1
Table 150: Partial Indicator
