Dialler Options 155
Dialler Options 3
LOCATION 179 (Default For Software Version 1.00 - 1.03 = 0) 2
Option Description
1
Set DTMF Dialling Pulses To 1 Digit/Second
2
Lockout Telephone Line Fail Alarm (New - Software Version 1.03)
4
Change Decadic Dialling To 60/40
8
Reserved
1
2
4
8
Table 73: Dialler Options 3
Set DTMF Dialling Pulses To 1 Digit/Second
If this option is not selected, the dialling format – Australian DTMF dials at the rate of 5 digits per
second (i.e.. 100 ms tone, 100 ms pause, 100 ms tone, 100 ms pause).
If this option has been selected, the dialling format – Australian DTMF dials at the rate of 1 digit per
second (i.e.. 500 ms tone, 500 ms pause).
Lockout Telephone Line Fail Alarm
(New - Software Version 1.03) This option if programmed will only allow an audible alarm once per
arming cycle when the control panel detects that the telephone line has been cut or disconnected. This
option bit does not follow the swinger shutdown count for siren where you can program how many
times a zone may sound an alarm during the arming cycle. Refer to LOCATION 176 on page 149 to
program the telephone line fault options.
Change Decadic Dialling To 60/40
Some countries have different requirements for decadic dialling. Setting this option will change the
dialling characteristics from 65/35 (Australian Standard) to 60/40. This option should only be set
when the control panel is used in a country that requires decadic dialling as 60/40. This option has no
effect when using DTMF tone dialling.
External Modem Module (CC811) Required For FSK
If this option is enabled, the control panel will use the FSK transmission frequency BELL 103 at 300
baud via the optional external Modem Module (CC811). Use the CC811 modem module for CCITT
V21 and use the CC811B modem module for Bell 103.
Electronics Design and Manufacturing Pty Limited ISSUE162.DOC
