54 Solution Ultima 844/862/880 Installation Manual
3
4
5
6
Tamper Fail
This fault will occur when any zone has become open circuit. By holding down button 3 until two
beeps are heard in fault analysis mode will display which zone has reported the tamper fail fault.
Sensor Watch Fault
A sensor watch fault will register because one or more detection devices has failed to detect any
intrusion during the disarmed state for the time period programmed by your installer. The fault will
clear once the zone in question has detected movement and reset.
Whilst you are in fault analysis mode, holding down button
4until two beeps are heard will display
which zone reported the sensor watch fault.
RF Sensor Watch Fault
An RF sensor watch fault will register because one or more wireless detection devices has failed to
detect any intrusion during the disarmed state for the time period programmed by your installer. The
fault will clear once the zone in question has detected movement and reset.
Whilst you are in fault analysis mode, holding down button
5until two beeps are heard will display
which zone reported the sensor watch fault.
Communication Fail
A communication fail will register when the control panel failed to communicate with the receiving
party (e.g.: monitoring company, mobile phone or pocket pager etc).
The communication fault will clear once the control panel has successfully reported to the receiving
party.
Whilst you are in fault analysis mode, holding down the
6 button until two beeps are heard will
display which communication fault has occurred (i.e.. 1 = Receiver 1 / 2 = Receiver 2).
AC Mains Failure
An AC mains supply failure will automatically flash the MAINS indicator. If the AC mains supply has
been disconnected continuously for more than two minutes, the remote codepad will beep the codepad
buzzer once every minute. If the control panel has been programmed to report an AC mains fail to a
base station receiver, an “AC Fail" report (Contact ID Event Code 301) will be sent.
The
MAINS indicator will cease to flash as soon as the AC mains supply has been reconnected. When
the AC mains supply has been continuously connected for a period of two minutes, the codepad will
cease the once a minute beep and an “AC Fail” restore report will be sent to the base station receiver.
If Option 1 – Enable AC Fail In 1 Hour in “LOCATION 438” on page 229 has been enabled, the
codepad will flash the
MAINS indicator as soon as the AC mains supply has been disconnected and
will not activate the dialler or the codepad buzzer unless the AC mains supply has been disconnected
continuously for a period of 1 hour.
If Option 2 – Ignore AC Mains Fail in “LOCATION 438” on page 229 has been enabled, the codepad
will not indicate when the AC mains supply has failed, but the control panel will still report if enabled
an "AC Fail" report.
ISSUE162.DOC Electronics Design and Manufacturing Pty Limited
