Partitioning 241
Programming
The following locations area only applicable when partitioning the Solution Ultima 880 control
panel. Remember that when programming option bit locations, you may add the options together
(e.g.: If you require both options 2 and 4, you would add the two options together and program a 6).
Partitioning Options 1
LOCATION 444 0
Option Description
1
First To Open/Last To Close Reporting
2
Area 1 Codepad Connected To Data Terminal
4
Reset Sirens From Any Area Allowed
8
Master Codepad To Display AUX Indicator When On-Line
Table 155: Partitioning Options 1
First To Open/Last To Close Reporting
1
This option needs to be enabled if only one Open/Close report is required when the system has been
partitioned. Rather than having individual Open/Close reports fore each area, a closing report will be
sent only when BOTH areas have been armed and an opening report will be sent as soon as one area
has been disarmed.
The reports will be sent on the Subscriber ID Number allocated to that particular area. Subscriber ID
Numbers and Open/Close reports must be programmed for both areas.
2
The option of first to open/last to close reporting is only applicable when all user codes have
their priority level set with no open/close reports. Therefore, if user codes have priority levels
set to open/close reports, an opening or closing report will always be reported when any area is
disarmed or armed irrespective of which area was first to open or last to close.
Area 1Codepad Connected To Data Terminal
If this option has been enabled, the DATA terminal on the Solution Ultima 880 control panel will
be configured to send status information only relevant to Area 1. This allows you to connect an area
addressable codepad (CP500A) set for Area 1 operation to the DATA terminal of the control panel
instead of connecting the addressable codepad to an output.
If this option has not been enabled, the CP5 Master Partitioned (CP500P) codepad will need to be
used as the DATA terminal on the control panel would display information for both Area 1 and Area
2.
An advantage in using this option is that it allows you to configure a system into separate areas while
still leaving the maximum number of programmable outputs available for other applications.
