Programmable Outputs 203
07 Exit Warning
This output operates during exit time when the system has been armed in AWAY Mode,
STAY Mode 1 or STAY Mode 2. The output will reset once exit time has expired.
08 Exit Warning Finished
This output operates when the exit time has expired when the system has been armed in
AWAY Mode, STAY Mode 1 or STAY Mode 2. The output will reset when the system
has been disarmed.
09 Kiss-Off After Exit Time
This output will operate after the first successful transmission to the base station receiver
when exit time has expired. The output will reset when the system has been disarmed.
0 Entry Warning
This output will operate when either Entry Timer 1, Entry Timer 2 or Entry Guard Timer
For STAY Mode are operating. The output will reset when the entry time expires.
0 Entry Warning + Day Alarm Resetting
This output combines both Entry Warning and Day Alarm Resetting so that either of these
two events will activate the output.
If the output has been triggered by either Entry Timer 1, Entry Timer 2, or Entry Guard
Timer For STAY Mode, the output will reset once the entry timer has expired or the system
has been disarmed.
If a zone programmed for day alarm has triggered during the disarmed state, the output will
reset when the zone has resealed. Day alarm may be turned on and off by holding down the
4 button. Refer to Day Alarm Zones on page 164 for programming zones to operate for
day alarm.
0 Exit Warning + Entry Warning + Day Alarm Resetting
This output combines exit warning, entry warning and day alarm so that any of these three
events will activate the output.
This output will activate once the system has been armed in AWAY Mode, STAY Mode 1
or STAY Mode 2 irrespective of any zones being sealed or unsealed until exit time expires.
The next time the output will activate will be during entry time and will reset once entry
time has expired or the system has been disarmed. This output will also operate when the
Entry Guard Timer For STAY Mode is timing.
If a zone programmed for day alarm has triggered during the disarmed state, the output will
reset when the zone has resealed. Day alarm may be turned on and off by holding down the
4 button. Refer to Day Alarm Zones on page 164 for programming zones to operate for
day alarm.
0 Day Alarm Resetting
This output will operate when a zone programmed for day alarm has been triggered. The
output will reset when the day alarm zone has resealed. Day alarm may be turned on and
off by holding down the 4 button. Refer to Day Alarm Zones on page 164 for
programming zones to operate for day alarm.
Electronics Design and Manufacturing Pty Limited ISSUE162.DOC
