EDM Solution Ultima 844 - Page 276

Location 000 – 015 Page 139
Primary Telephone Number For Receiver 1
Location 016 – 031 Page 139
Secondary Telephone Number For Receiver 1
Location 032 Page 140
Handshake Tone For eceiver 1
Location 033 Page 141
Transmission Format For Receiver 1
Location 034 – 039 Page 141
Subscriber ID Number For Receiver 1
Location 040 – 055
Page 142
Primary Telephone Number For Receiver 2
Location 056 – 071 Page 142
Secondary Telephone Number For Receiver 2
Location 072 Page 143
Handshake Tone For Receiver 2
Location 073 Page 144
Transmission Format For Receiver 2
Location 074 – 079 Page 144
Subscriber ID Number For Receiver 2
Location 080
Page 145
Dialling Format
Location 081 – 112
Page 145
Reserved
Location 113 –142 Page 146
Telco Arming Sequence
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Location 143 – 158 Page 147
Telco Disarming Sequence
Location 159 – 174
Page 147
Call Back Telephone Number
Location 175 Page 148
Ring Count
Location 176 Page 149
Telephone Line Fault Options
0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0
1 = HI-LO Handshake (Contact ID) 4 = No Handshake Required
2 = 1400 Hz (TX @ 1900 Hz) 5 = Pager
3 = 2300 Hz (Low Speed Sescoa)
1
1 = Contact ID 5 = Basic Pager
2 = 4 + 2 Express 6 = Reserved
3 = FSK 300 Baud 7 = Reserved
4 = Domestic 8 = Reserved
1
0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0
1 = HI-LO Handshake (Contact ID) 4 = No Handshake Required
2 = 1400 Hz (TX @ 1900 Hz) 5 = Pager
3 = 2300 Hz (Low Speed Sescoa)
1
1
1 = Contact ID 5 = Basic Pager
2 = 4 + 2 Express 6 = Reserved
3 = FSK 300 Baud 7 = Reserved
4 = Domestic 8 = Reserved
0 0 0 0
1
1 = Australian DTMF (5 Digits/Second) 4 = International DTMF
2 = Australian Decadic 5 = Reversed Decadic
3 = Alternate DTMF & Decadic (AUST) 6 = Alternate DTMF & Reversed Decadic
0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0
8
0 = Panel Will Not Answer 14 = Answering Machine Bypass 2
1 – 13 = No Of Rings Until Panel Answers 15 = Answering Machine Bypass 1
1 = Display FAULT Indicator When Telephone Line Fails
2 = Sound Alarm When System Is Armed
4 = Sound Alarm When System Is Disarmed
8 = Reserved
0
276 Solution Ultima 844/862/880 Installation Manual
ISSUE162.DOC Electronics Design and Manufacturing Pty Limited
