Zone Pulse Count Settings
The pulse count settings for each zone can be programmed between 0 - 15.
Zone Pulse Count Time
Zone pulse count time is the time frame or period over which the number of pulses must register.
20 ms Loop Response Time
Zone Pulse Count Time
150 ms Loop Response Time
Zone Pulse Count Time
0
0.5 Second
8
20 Seconds
1
1 Second
9
30 Seconds
2
2 Seconds
10
40 Seconds
3
3 Seconds
11
50 Seconds
4
4 Seconds
12
60 Seconds
5
5 Seconds
13
90 Seconds
6
10 Seconds
14
120 Seconds
7
15 Seconds
15
200 Seconds
Table 170: Zone Pulse Count Time Options
Zone Options 1 Zone Options 2
Option Description Option Description
1
Lockout Siren/Lockout Dialler
1
Isolated In STAY Mode 1
2
Delay Alarm Reporting
2
Zone Isolation Allowed
4
Silent Alarm
4
Forced Arming Allowed
8
Sensor Watch
8
Enable Zone Restore Report
Table 171: Zone Options 1
Zone Dialler Options
Table 172: Zone Options 2
Option Description
0
No Report Required
1
Receiver 1
2
Receiver 2
4
Receiver 1 + 2
8
Receiver 2 Only When Receiver 1 Fails
Table 173: Zone Dialler Options
Zone Descriptions
Use this table as a reference to indicate what each zone is connected to.
Zone Description Zone Description
1 5
2 6
3 7
4 8
Table 174: Zone Descriptions
