EDM Solution Ultima 844 - Page 303

Location 440 Page 231
Consumer Options 1
Location 441 Page 232
Consumer Options 2
Location 442
Page 233
Consumer Options 3
Location 443
Page 234
Radio Input Options
Location 444
Page 241
Partitioning Options 1
Location 445
Page 242
Partitioning Options 2
Location 446 – 453
Page 243
Zone Allocations For Area 1
Location 454 – 461 Page 243
Zone Allocations For Area 2
Location 462 – 477
Page 245
User Code Allocations
Location 478 – 525 Page 127
Domestic Telephone Numbers
Location 526
Reserved
Location 527 Page 250
RF Option
1 = Test Reports Only When Armed
2 = Test Report After Siren Reset
4 = Auto Arm In STAY Mode 1
8 = STAY Indicator To Display Day Alarm Status
0
1 = Codepad Extinguish Mode
2 = Single Button Arming Allowed (AWAY Mode, STAY Mode 1 & 2)
4 = Single Button Disarming From STAY Mode 1 & 2)
8 = Alarm Memory Reset On Disarm
2
5
1 = Codepad Fault Alarm Beeps Allowed
2 = Use Digit 3 For Codepad Duress Instead Of Digit 9
4 = Alarms Activate Siren & Strobe In STAY Mode 1 and STAY Mode 2
8 = Zone Tamper Alarms To Be Silent
1 = DS 304 MHz Receiver (RF3212)
2 = Latching Keyswitch Input
3 = Momentary Keyswitch Input
4 = Reserved
0
0
1 = First To Open/Last To Close Reporting
2 = Area 1 Codepad Connected To Data Terminal
4 = Reset Sirens From Any Area Allowed
8 = Master Codepad To Display AUX Indicator When Using Telephone Line
1 = Lock Area 1 To Receiver 1 and Lock Area 2 To Receiver 2
2 = User Code Allowed To Arm/Disarm Both Areas At same Time (Code + 0 + #)
4 = Reserved
8 = Reserved
0
0 0 0 0 0
0 0 0 0 0
Location 462 Location 463 Location 464 Location 465
Areas For User #1
0
Areas For User #2
0
Areas For User #3
0
Areas For User #4
0
Location 466 Location 467 Location 468 Location 469
Areas For User #5
0
Areas For User #6
0
Areas For User #7
0
Areas For User #8
0
Location 470 Location 471 Location 472 Location 473
Areas For User #9
0
Areas For User #10
0
Areas For User #11
0
Areas For User #12
0
Location 474 Location 475 Location 476 Location 477
Areas For User #13
0
Areas For User #14
0
Areas For User #15
0
Areas For User #16
0
0
0
1 = Sound Siren On RF Receiver Fail
2 = Sound Siren On RF Receiver Tamper / Jamming
4 = Unseal Zone That Fails Supervision (Only If Supervision Enabled)
8 = Enable RF Jamming Monitoring
Solution Ultima 880
Programming Sheets 303
Electronics Design and Manufacturing Pty Limited ISSUE162.DOC
