Solution Ultima 844/862/880 Installation Manual
Zone
Indicator
Fault
Description
Hold Down
Button
Zone
Indicator
Fault
Condition
1 System Fault
1
1
Low Battery
2
Date & Time
3
RF Receiver Jamming
RF Receiver Tamper Switch
RF Receiver Comms Failure
4
Horn Speaker
5
Telephone Line Fail
6
E2 Fault
7
Fuse Fail
2
RF Low Battery
2
1 - 8
Zones 1 - 8 RF Low Battery
3 Zone Tamper Alarm
3
1 - 8
Zones 1 - 8 Tamper Alarm
4 Sensor Watch Fault
4
1 - 8
Zones 1 – 8 Sensor Watch
Fail
5 RF Sensor Watch
5
1 – 8
Zones 1 - 8 RF Sensor Watch
Fail
6 Communication Fail
6
1
Receiver 1 Fail
2
Receiver 2 Fail
Table 25: Fault Indicators
