Frontier LP7700 - Page 453

3/13
4. Troubleshooting
40900
40900
Attention message: F replenishment
No. 00905[F]
Install the new replenisher cartridge.
Attention message release
YES
IMPORTANT
• If the above attention message is shown, do not click YES to close it and continue the printing process without performing
the diagnosis below.
After a set number of prints are output,
☞No. 05912[F] Predetermined process amount was exceeded. will be shown,
and then printing cannot be performed.
Condition
NOTE
• The cartridge installation section is raised, and the attention message appears.
Check Point
Diagnosis
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00000 If all the sensors below detect OFF although 40 seconds has passed after the replenishment cartridge opened.
• P1R (Lower) Replenishment Solution Level Sensor
• P2RA (Lower) Replenishment Solution Level Sensor
• P2RB (Lower) Replenishment Solution Level Sensor
For details of operation specification, see ☞ 57010.
Check that an empty replenisher cartridge is not set. -
Check the Replenisher Cartridge Set Sensor status via Input Check.
☞35220
Failed part Manual No.
• P1R (Lower) Replenishment Solution Level Sensor
• P2RA (Lower) Replenishment Solution Level Sensor
• P2RB (Lower) Replenishment Solution Level Sensor
☞63280
F replenishment I/O PCB
☞66800
Processor control PCB ☞66200
