4. Troubleshooting
45900
6/16
45900
Error message: F replenishment
No. 05908[F]
Failed to open the replenisher cartridge.
Error message release
YES
IMPORTANT
• If the above error message is shown, do not click YES to close it and continue the printing process without performing the
diagnosis below.
After a set number of prints are output,
☞No. 05912[F] Predetermined process amount was exceeded. will be shown,
and then printing cannot be performed.
NOTE
• If printing process is continued after the above error is shown, the time is counted as Replenishment Lack Time and the P1R, P2RA
and P2RB replenishers will not be replenished.
Condition
Check Point
Diagnosis
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
- Even though 40 seconds has passed after the replenishment cartridge opened, # # # (lower) replenishment
solution level sensor of each processing solution does not detect ON.
Suffix number Condition
00001 P1R
00002 P2RA
00004 P2RB
For details of operation specification, see ☞ 57010.
• For the QSS-3701/3702/3703/LP7500/LP7600, about 507 prints whose size is 127 mm × 89 mm can be processed after the error
occurs.
• For the QSS-3704/3705/LP7700/LP7900, about 545 prints whose size is 127 mm × 89 mm can be processed after the error occurs.
Countermeasure
1. Perform recovery procedure 1 from the replenishment error.
☞4610
Check the status of the replenishment solution level sensors of each processing solution with Input Check.
☞35220
Failed part Manual No.
P1R (Upper) Replenishment Solution Level Sensor
☞63280
P2RA (Upper) Replenishment Solution Level Sensor
P2RB (Upper) Replenishment Solution Level Sensor
F replenishment I/O PCB
☞66800
Processor control PCB ☞66200
