Fujitsu 1FINITY L100 User Manual

4.6
Install 23-Inch, 2-Post Rack Rail Kit
Prerequisites:
■ The 23-inch, 2-post EIA-310 compliant rack is installed according to local standards.
■ Hex-nut driver set and socket wrench set
■ Screwdriver set (including straight-slot and Phillips head)
■ Small level
Step 1
Determine the le and right bracket for installaon.
Note: Each bracket is labeled le or right as shown in the following gure.
s8101bi_1
Figure 38
Le and Right Bracket Labels
Step 2
Loosen the ange nuts on both the le and right brackets, as shown in the following gure.
Note: Do not completely remove the nuts from the ange.
Equipment Installation
Install 23-Inch, 2-Post Rack Rail Kit
113
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
