5.6.3
Congure IP Connection Through OSC
Prerequisite:
■ The NE is installed and powered up, OSC is congured, and DCN connecvity is available through the
transport network using OSC.
Aenon: To connect the NE to the DCN through the OSC, the user must rst turn up the OSC, which
requires signicant OSC provisioning. OSC turn-up is not covered in this chapter because it ts in the
chapter that covers turn-up of the NE transport funcons.
The following gure shows a WDM network composed of 1FINITY ROADM and ILA NEs. The NEs at Site A and Site
B connect to the DCN through the LCN1 interface. All other NEs connect to the DCN through OSC links.
Remote Users
Virtuora User
Interface
WebGUI
CLI
NETCONF/
YANG
Router
Switch
LAN cable
Virtuora NC
LAN
LAN
DCN
Router
Switch
LAN cable
1FINITY
ILA
1FINITY
ROADM
1FINITY
ROADM
OSC
1FINITY
ROADM
1FINITY
ILA
1FINITY
ROADM
OSC
Site A
Site B
1FINITY
ROADM
LCN1
1FINITY
ROADM
LCN1
OSC
OSC
Figure 91
WDM Network
OSC is required (must be turned up) between every pair of adjacent NEs in the 1FINITY WDM network because it
(OSC) supports various required funcons, for example, opcal power management and LLDP. If needed, OSC can
carry DCN trac.
Note: In this procedure, roung instances are congured with OSPF roung protocol. If desired, roung
instances can be congured stacally (using the stac roung protocol and next-hops).
Initial System Turn Up
Congure IP Connection to DCN
176
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
