â–  Total loss (bulk loss) between L160 Raman blade and the outside plan transmission line is <1 dB
■ Accumulated loss in the ber (splices and connectors loss), parcularly in the rst 20 km, should be kept to a
minimum as this could aect Raman gain. Performance is best with the cleanest possible transmission line.
1.8.5
4x16 Splitter/Coupler Specications
Table 7
General Specicaons
Property Specicaon
Weight 3.483 lb (1.58 kg)
Dimensions (H x W x D) 1.52 x 6.89 x 9.67 in. (38.7 x 175.1 x 245.5 mm)
Operang temperature range –5…40 °C
Storage temperature range –40…70 °C
Humidity range 5…93%
Number of ports/circuits 20 pairs of opcal ports (transmit/receive)
Connector type LC opcal port
Power consumpon ■ Typical: 33 W (esmated)
■ Maximum: 58 W (esmated)
Table 8
Opcal Specicaons
Property
Opcal Power (dBm)
Comment
Minimum Maximum
C1–C16 IN
Opcal input power
–6.0 7.6 Maximum 1 channel per port
C1–C16 OUT
Opcal output power
–10.0 10.1 Maximum 1 channel per port
E1–E4 IN
Opcal input power
–9.5 5.0 Maximum 16 channels per port
E1–E4 OUT
Opcal output power
–7.4 10.8 Maximum 16 channels per port
System Description and Engineering
Engineering Specications
59
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
