Install 19-Inch, 4-Post Rack Rail Kit
Prerequisites:
■ The 19-inch, 4-post EIA-310 compliant rack is installed according to local standards.
■ Hex-nut driver set and socket wrench set
■ Screwdriver set (including straight-slot and Phillips head)
■ Small level
Step 1
Determine the le and right bracket for installaon.
Note: Each bracket is labeled le or right as shown in the following gure.
s8101bh_1
Figure 45
Le and Right Bracket Labels
Step 2
Loosen the ange screws on both the le and right brackets, as shown in the following gure.
Note: Do not completely remove the screws from the ange.
Equipment Installation
Install 19-Inch, 4-Post Rack Rail Kit
