Fujitsu 1FINITY L100 User Manual

2.2
L100 Blade
In this secon:
2.2.1 Connector Descripons
2.2.2 LED Descripons
The L100 (BDL1-3R11) 9-port ROADM RoB has nine client ports and one edge port and includes a built-in
universal amplier. Up to four degrees of C/CD ROADM and 128 100 Gb/s or higher (including 150 and 200 Gb/s)
channels are supported.
One L100 Blade is required for each degree of ROADM. The following gures show front and rear views of the
L100 Blade.
FG
ESD
1FINITY L100
FNC000975_Rev_02
Figure 14
Front View of 1x9 WSS L100 6-port ROADM ROB (Issue 13 and earlier)
Figure 15
Front View of 1x9 WSS L100 6-port ROADM ROB (Issue 14 and later)
Note: Issue 05 and earlier units have opcal port direcon labels O/I instead of T/R.
,10A MAX，
FUSED AT 15A
INPUT RATING:
-40 TO -57V
2 1
FAN
MAINT
FG
ESD
s8104ag_1
Figure 16
Rear View of L100 Blade 1x9 WSS ROB
Unit Description
L100 Blade
65
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
