Table 14
Physical Characteriscs
Dimensions (H x W x D) Weight Rack Compability
1.75 x 19.00 x 17.72 in. (44.45 x 483.00 x
450.00 mm) W=19 or 23 in. with mounng
rails
Note: The depth dimension is without the
ber management. The depth dimension
with ber management is less than 23.62 in.
(600 mm).
■ L100 chassis: 8.10 kg (17.857 lb)
■ L110 chassis: 6.08 kg (13.404 lb)
■ L130 chassis: 10.3 kg (21 lb)
■ 4x16 PIU: 1.58 kg (3.483 lb)
19 and 23 in.
Table 15
Operang Environment
Operang Temperature Short-Term Temperature Normal Operang Humidity Short-Term Humidity
5…40 °C –5…50 °C 5…85% noncondensing 5…93% noncondensing
Table 16
Power
Power Supply 120 V AC –48 V DC Power Dissipaon
Dual feed, xed power supplies No –40…–57 V DC ■ L100: 217.32 W (typical)
■ L110: 177.5 W (typical)
■ L130: 217.32 W (typical)
Table 17
ROADM Capacity and Funcons
Conguraon ROADM Degrees Topology Wavelengths
Wavelength
Range
Maximum
Channels Per
Degree
Maximum
System Capacity
Span Loss OSC
CD, direct access
(C), mix
conguraon
ROADM
Up to 4 P-to-P, Linear,
Ring, Mesh
100G, 200G 1528.77…1566.77
nm
96 (50 GHz ITU-T
xed grid), 128
(37.5 GHz ITU-T
exible grid)
25.6T (200Gx128
channels) per
degree
0…35 dB
L130 Blade
without L160
Blade: 0…34 dB
(SMF), 0…35 dB
(TWRS/TWC,
ELEAF/OLEAF DSF,
EXTCore)
L130 Blade with
L160 Blade: 16…
35.5 dB (SMF),
16…36 dB (TWRS/
TWC), 16…36.5 dB
(ELEAF/OLEAF,
DSF)
OC-3, 100 Mb/s
Ethernet, Gigabit
Ethernet
Unit Description
Technical Specications
