Fujitsu 1FINITY L100 - L110 Blade LED Indicators

Table 48 (Cont.)
LED and Condion
LED Color Condion
SYS Green Normal operaon
Yellow Not ready (warm-up or SWDL in progress)
One of the following alarms is present:
■ databaseCorrupon
■ databaseLockedDbAlarmPresent
■ databaseLockedDbRestoreInProgress
■ databaseLockedIlfViolaon
■ databaseLockedShelfProvModePresent
■ databaseLockedSowareUpgradeInProgress
■ databaseVersionMismatch
■ equipmentWarmup
■ rmwareBackwardCompableAll
■ rmwareDownloadOrAcvaonFailure
■ rmwareInitInProgress
■ rmwareVersionMismatch
■ shelfProvisioningMode
■ sowareStageInProgress
■ sowareVersionMismatch
Red Equipment fault
Equipment in power-up state
Blinking red MEA
O Power o
8.1.2
L110 Blade LED Indicators
The following gures show front and rear views of the Opcal Mux Base blade.
FG
ESD
1
FNC000978_Rev_01
Figure 104
Front View of L110 Opcal Mux Base Blade
System Maintenance
Trouble Clearing
287
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
