8.1.4
PIL1-3PS2 PIU LED Indicators
The following gure shows the front view of the PIL1-3PS2 PIU.
R T R T
C16
R T R TR T R TR T R T
C9
TTR R
E4E3
R T
C8
RTR T RTRTRTT R T R
C1
T R T R
E2 E1
F/S
E
C
FC95453PS2
FNC000979_Rev_02
Figure 109
Front View of PIL1-3PS2
Note: Issue 04 and earlier units have opcal port direcon labels O/I instead of T/R.
Table 51
LED and Condion
LED Color Condion
C Red C1…C16 port input down
C1…C16 port power out of specicaon
Green Incoming opcal signal operang normally
O Power o
E Red E1…E4 port input down
E1…E4 port power out of specicaon
Green Incoming opcal signal operang normally
O Power o
F/S Red Equipment fault or equipment in power-up state
Blinking red MEA
Yellow Not ready (warm-up or SWDL in progress)
Green Normal operaon
O Power o
System Maintenance
Trouble Clearing
293
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
