Congure LCN1 with Static IP Address
Prerequisite:
■ If port LCN1 requires a pluggable SFP module, the SFP is installed and its autoprovisioning is complete.
Overview
At the site where the NE is installed, the Local Area Network (LAN) connects to a router and the DCN is reachable
through the router. This secon describes the procedure to congure a stac IP address on LCN1, congure the
default next-hop IP address, and install a LAN cable connecng LCN1 to the LAN. The LAN cable can connect
directly to a LAN switch port as shown in the following gure.
Virtuora User
Interface
WebGUI
CLI
NETCONF/
YANG
Router
Next-hop IP address
Virtuora NC
DCN
Switch
LAN
Remote Users
NE Installation Site
1FINITY NE
LCN1
LAN cable
Figure 87
LAN Switch Port Connecon
The following gure shows how to save LAN switch ports by connecng the LAN cable to a daisy chain of LAN
cable connecons between 1FINITY NEs.
Virtuora User
Interface
WebGUI
CLI
NETCONF/
YANG
Router
Next-hop IP address
Virtuora NC
DCN
Switch
LAN
NE Management
Mode = Bridge
1FINITY NE
1FINITY NE
1FINITY NE
LCN1
LCN2
LCN2
LCN1
LCN1
LAN cable
Remote Users
NE Installation Site
Figure 88
Daisy Chain LAN Connecon
Initial System Turn Up
Congure IP Connection to DCN
170
Release 19.1.1 · Issue 1.1, May 2021
Fujitsu and Fujitsu Customer Use Only
