Fujitsu 1FINITY L100 - Adjustable Range of Rack Brackets

4.4
Adjustable Range of Rack Brackets
The following table lists the adjustable range of the rack brackets.
Note: The adjustable range is the width between the front and rear anges of the bracket.
Table 42
Adjustable Range of Rack Brackets
Conguraon Part Number Descripon Adjustable Range
Housing (aggregated) FC9549HF11 Flange for 6-blade Housing, 19-inch, 2-post rack 127.0…128.8 mm
FC9549HF21 Flange for 6-blade Housing, 19-inch, 4-post rack 566.3…784.1 mm
FC9549HF31 Flange for 6-blade Housing, 23-inch, 2-post rack 127.0…128.8 mm
Standalone
(disaggregated)
FC9549SR11 Mount rail for standalone blade, 19-inch, 2-post rack 127.0…180.0 mm
FC9549SR21 Mount rail for standalone blade, 19-inch, 4-post rack 367.0…460.0 mm
FC9549SR31 Mount rail for standalone blade, 23-inch, 2-post rack 127.0…180.0 mm
FC9549SR41 Mount rail for standalone blade, 23-inch, 4-post rack 367.0…460.0 mm
Equipment Installation
Adjustable Range of Rack Brackets
