equipmentLedOn
Enty Type Severity
Service
Aected
Direcon Locaon Descripon
PIL1-3PS2 warning non–service-
aecng
n/a NEND Equipment Common Visual LED Acvated:
TYPE = <unit type>
Probable Cause Suggested Correcve Acon
An LED on the PIU has been intenonally
acvated.
Deacvate the LED.
BDL1-3M21, BDL1-3R11,
BDL1-3B11
warning non–service-
aecng
n/a NEND Equipment Common Visual LED Acvated:
TYPE = <unit type>
Probable Cause Suggested Correcve Acon
An LED on the blade has been intenonally
acvated.
Deacvate the LED.
equipmentMiscabledConnection
Enty Type Severity
Service
Aected
Direcon Locaon Descripon
1GEX, 1GEBT major non–service-
aecng
n/a NEND Interblade communicaon Miscabled
Connecon: TYPE = <unit type>
Probable Cause Suggested Correcve Acon
The interblade communicaon cables are
not installed correctly.
Perform eqpt-reset with reset ADOPTSHELF.
> request eqpt-reset shelf-id 1 reset
ADOPTSHELF
equipmentMismatchAttributes
Enty Type Severity
Service
Aected
Direcon Locaon Descripon
AC00-F011 warning non–service-
aecng
n/a NEND Mismatch of Equipment and Aributes:
TYPE=<unit type> and the admin-status is
down
Probable Cause Suggested Correcve Acon
■ A Fan unit is mismounted.
■ A Fan unit slot is not provisioned
correctly.
1. Remove and remount the Fan unit.
2. Correct the Fan unit slot provisioning.
